当前位置:首页 > 产品中心 > TFT全彩液晶显示模块
点击放大
5.0”TFT
产品详情
序号产品尺寸分辨率显示比例 LCM尺寸(W*H*T)  通信接口  PIN数 参考型号
10.96寸80*160IPS竖屏 13.5*27.95*1.47mm  MCU  24Pin T096P05
21.54240*240IPS横屏31.52*33.72*1.73mmSPI10PinT154P16
31.77寸128*160TN竖屏34*43.78*2.3mmMCU24WK17775
42.0寸 240*320IPS竖屏 36.02*51.59*1.7  RGB  40pin T20P217
5480*360 IPS横屏46.1*40.96*2.54mmRGB/MIPI40PinT20P162-01
62.31寸480*360 IPS横屏51.3*46.3*2.36MIPI27pinT23P33
7480*360 IPS横屏55.2*47.55*2.8RMB30pinT23P32
82.36寸320*240TN横屏 36.02*51.59*1.7  RGB  40Pin WK24241
92.4寸240*320TN竖屏 42.7*60.2*2.4  MCU 37PinWK24215
10 240*320IPS竖屏42.72*60.26*2.15mm MCU 39PinWK24275
112.8寸 240*320 TN竖屏50*69.2*2.45mmMCU37PinWK28184
12240*320 IPS竖屏49.60*69.0*2.06mmMCU/SPI24PinT28P29
13240*320 IPS竖屏 50*69.2*2.50mm  RGB  45Pin  T28P119
143.0寸 360*640  IPS竖屏43.44*75.31*2.6mmMIPI/RGB40PinT30P131
153.1寸480*800IPS竖屏43.68*77.02*1.65mm MIPI27PinT31P06
163.2寸 240*320 TN竖屏57.54*79.2*3.3mmMCU40PinWK32061
17 240*320 TN竖屏55.04*77.7*2.5mmSPI10pinWK32066
18376*960 IPS竖屏 31.2*76.6*2.4mm  MIPI  12pin  T32P11
193.5寸 320*480 TN竖屏54.48*84.71*2.05mmRGB45PinWK35143
20 320*480 TN竖屏55.26*84.69*2.15mmMCU46PinWK35201
21 320*240 TN横屏76.9*63.9*3.1mmRGB54PinWK35190
22 320*240 IPS横屏76.95*63.95*3.2RGB54PinWK35163
23320*480IPS竖屏55*82.94*2.18SPI10PINT35P78
243.95 480*480 IPS横屏74.83*78.98*2.0RGB50pinT395P05
25720*720IPS横屏74.27*78.67*1.51MIPI30pinT395P13
263.97寸480*800  TN竖屏57.14*96.85*2.2mmRGB31PinT397P04
27480*800TN竖屏57.14*96.85*2.2mmMIPI31PinT397P26
28480*800 IPS竖屏57.14*96.85*2.15mmMIPI25PinT397P08
294.3寸480*272 TN横屏105.5*67.2*2.9mmRGB40PinWK43174
30480*272IPS横屏105.5*67.2*2.9mmRGB40PinT43P82
31 800*480 IPS横屏105.5*67.2*2.9mmRGB40PinWK43188
32 480*800 IPS竖屏60*104.25*2.05MIPI20pinWK43234
335寸  720*1280 IPS竖屏65.26*119.3*1.79mmMIPI24PINT50P129
34 480*854 IPS竖屏66.4*120*2.35mmRGB40PinT50P37
35 800*480IPS横屏120.70*75.8*2.85mmRGB40PinWK50092
366.86480*1280 IPS竖屏181.0*66.6*4.35mmMIPI40PinT68P27
377寸 800*480 TN横屏 164.9*100*4.7  RGB  50pin WK70273
38 1024*600 TN横屏164.86*99.96*3.5 LVDS 40PinT70P227
39 1024*600  IPS横屏164.9*100*2.73RGB50pinT70P180
40 1024*600  IPS横屏164.75*99.80*2.87MIPI40PINT70P206
41 800*1280  IPS竖屏99.85*161.7*2.6  MIPI 24PinT70P196
428寸 800*1280  IPS竖屏114.7*184.2*2.6mmMIPI24pinT80P105
4310.1寸 1024*600TN横屏 235*143*2.9  LVDS  40Pin WK10134
441024*600 IPS横屏 235*143*4.55  LVDS 60PinT101P11-01
45 800*1280 IPS竖屏142.64*228.55*4.5MIPI40PinT101P39
461920*1200IPS横屏229.32*148.96*2.47mmLVDS45PinT101P55
4710.251280*480IPS横屏258.60*107.00*6.31mmLVDS/RGB60PinT1025P00
481920*720IPS横屏258*60*107.55*6.31mmLVDS50pinHSD103JPW2-F10-HY
